MTU, 12V4000 L33, 2023, Natural Gas Trigeneration Plant, 1,262 kWe, Carrier Absorption Chiller

Reference V-2966

Brand MTU

Model 12V4000 L33

Year built 2023

Condition Unused, 0 hours

Quantity 1 machine



Overview

Trigeneration plant (combined cooling, heat and power) with a rated electrical output of 1,262 kW

Year of construction: 2023

Plant assembled and never put into operation: CHP unit and absorption unit both new, 0 hours

CHP unit: MTU 12V4000 L33 natural gas generator set in an enclosed container, type E1265 250 NOx L33 natural gas CHP unit

Absorption unit: Carrier 16LJ-F41 in an enclosed container

2 evaporative cooling towers, new, 0 hours

CHP Unit Performance

Rated electrical power: 1,262 kW

Thermal power: 1,355 kW

Electrical efficiency (cos f = 1.0): 42.1%

Thermal efficiency: 45.2%

Total efficiency (full heat recovery): 87.3%

Fuel consumption at 100% load: 299 Nm³/h

Fuel consumption at 75% load: 232 Nm³/h

Fuel consumption at 50% load: 167 Nm³/h

Engine and Generator

Engine: Rolls-Royce MTU 12V4000 L33 gas engine, V12

Maximum engine power: 1,320 kW

Alternator: Stamford PE734E-312, three-phase, synchronous, four-pole, brushless

Rated apparent power: 1,935 kVA

Rated voltage: 400 V

Frequency: 50 Hz

Configuration: containerized

CHP container dimensions (L x W x H): 12,800 x 2,700 x 2,900 mm

Cooling: water-cooled

Absorption Unit (Carrier 16LJ-F41)

Cooling capacity: 1,178 kW

Chilled water circuit: flow rate 56.4 L/s, pressure 45 kPa, DIN connection 8 in, volume 0.48 m³

Heat rejection circuit: flow rate 93.1 L/s, pressure 117 kPa, DIN connection 10 in, volume 1.39 m³

Dimensions (L x H x W): 5,330 x 3,080 x 1,690 mm

Weight: 13,700 kg (30,203 lb)

Documentation

Documentation and manuals included

Genset technical data sheet, CHP energy balance and load data, absorption chiller selection data and dimension drawing available
