Mitsubishi Used 30MW Steam Turbine Power Plant 2015

PRICE of 30 MW: FOB JAPANESE PORT 7,500,000 US Dollars



FOB PRICE includes equipment price, dismantling cost, inland transportation cost and the cost of loading equipment on a ship at a Japanese port.



Used 30MW Steam Turbine Power Plant

Manufacturer: Mitsubishi -Hitachi(Japan)



Type; Single Casing turbine, Impulse turbine, condensing turbine,



Reduction gear box type,



Manufacturing year: 2015



Output: 30,000KW



Main steam pressure(MSV inlet): 10.5MPa



Main steam temperature(MSV inlet): 540°C



Extraction steam pressure(turbine extraction inlet): 0.525MPa



Air Supply steam pressure( at the collection point ):0.46MPa



Air supply steam temperature( at the collection point ): 170°C



Degree of vacuum: 7.3kPa



Speed: 5982 rpm(not 1800rpm)



(Alternator)



Manufacturer: Mitsubishi (Japan)



Manufacturing year: 2015



Type: Air cooled, Synchronous



Output: 35,295kVA



Frequency: 60Hz



Voltage: 11000V



Amps: 1853



Speed: 1800rpm



Power factor: 0.85



Frequency: 60HZ



Phase: 3



Poles: 4



Inlet air temperature: 45°C



Ex. Volts: 120V



Field Amps: 910A



(Boiler)



Manufacturer: Mitsubishi (Japan)



Manufacturing year: 2015



Pressure: 10.6MPa



Steam production capacity: 118ton/h(Max.)



Steam temperature: 551°C(3rd super heater outlet ) / 543°C(normal)



Steam pressure : 13.2 MPa(max.) / 11.8MPa(normal, 3rd super heater outlet)



Fuel: pulverized coal
